BendPak 16AP

7,257 kg super-duty clearfloor two-post hoist for larger work trucks, commercial fleets and workshops operating beyond normal lightvehicle capacities.
Get a Vehicle Hoist Quote
View Specifications
Call Iron Lift

Clear-floor two-post

BendPak 16AP

7,257 kg Super-Duty Clearfloor Two-Post Hoist

7,257 kg super-duty clearfloor two-post hoist for larger work trucks, commercial fleets and workshops operating beyond normal lightvehicle capacities.

Freight and installation options available — contact us for details.

Request a Quote
Ask About Installation
Call (08) 9249 5550
Quote only · Supply, installation planning, service, and spare parts from Malaga, WA
7,257 kg
Rated capacity
Super-duty high-rise clearfloor two-post
Configuration
4,293 mm
Overall height
2,616 mm
Drive-through clearance

Product overview

The BendPak 16AP steps the AP two-post platform into a 7,257 kg capacity class. Its wider overall structure, long symmetric arm reach and higher minimum pad position are aimed at larger vehicles rather than low passenger cars. The clearfloor format preserves access beneath the vehicle for workshop equipment, making the 16AP relevant to fleet, commercial and industrial maintenance where a two-post layout is still preferred. Australian supply and exact power configuration should be confirmed with Genesis before the page is made live.

Key features

  • 7,257 kg rated lifting capacity
  • 1,814 kg published maximum per arm
  • Super-duty clearfloor configuration
  • Approx. 2,096 mm published maximum lifting height with pad/adapter configuration
  • 4,267 mm overall width
  • 3,048 mm between columns
  • 2,616 mm drive-through clearance
  • 927-1,651 mm arm reach front and rear
  • Dual direct-drive hydraulics
  • 45-second published lifting time

Detail photography

Heavy-duty columns and baseplates
Long symmetric arm assemblies
Automatic arm restraint system
Direct-drive hydraulic cylinders
Large carriage construction
Safety-lock and overhead shutoff system

Ideal for

Commercial fleet workshops, truck and utility-vehicle service bays, mining-support workshops and industrial facilities servicing larger vehicles within the approved two-post lifting envelope.

Specifications

Specifications

Details

Capacity
7,257 kg
Configuration
Super-duty high-rise clearfloor two-post
Overall height
4,293 mm
Overall width
4,267 mm
Drive-through clearance
2,616 mm

Factory dimension drawing

Letters A–F match the diagrams above. Figures follow the Iron Lift FORGE 45DA factory sheet. Confirm before locking brochure artwork or a firm install quote.

Field

Letter

Value

Public model
BendPak 16AP
BendPak SKU
5175608
Rated lifting capacity
7,257 kg
Maximum load per arm
7,257 kg
Configuration
Super-duty high-rise clearfloor two-post
Rise
1,924 mm
Published lifting height
1,994 mm rise + pad; up to 2,096 mm published maximum with pad/adapter configuration
Minimum pad / lifting height
197 mm
Time to full rise
45 seconds
Overall height
4,293 mm
Overall width
4,267 mm
Width between / inside columns
3,048 mm
Drive-through clearance
2,616 mm
Front arm reach
927-1,651 mm
Rear arm reach
927-1,651 mm
Power unit
5 HP; Australian voltage/frequency and supply package to be confirmed before publication
Model-specific note
16,000-lb / 7,257 kg super-duty AP-series model; Australian supply not currently surfaced on Genesis BendPak brand page

Letters A–F match the diagrams above. Figures follow the Iron Lift FORGE 45DA factory sheet. Confirm before locking brochure artwork or a firm install quote.

Field

Letter

Value

Public model

Lifting time

Max lifting height without adapter

Max lifting height with adapter

Max lock height without adapter

Max lock height with adapter

Overall height

Overall width

Drive-through clearance

Width between columns

Minimum pad height

Short arm reach

Long arm reach

Gross weight

Pad / pin

What’s included

  • Two-post hoist structure, columns and base plates for the exact model.
  • Model-specific lifting-arm assemblies and vehicle-contact pads/adapters supplied with the Australian package.
  • Hydraulic lifting system, power unit, equalisation system and safety-lock system.
  • Automatic Swing Arm Restraint System (ASARS) where specified for the exact AP-series model.
  • Overhead safety shut-off arrangement on clearfloor models.

Options

  • Compatible truck/van height adapters and frame-contact accessories approved for the exact model.
  • Pinch-weld pads/pucks, frame cradle pads and replacement contact-pad options where compatible.
  • Wheel spotting accessories and compatible workshop accessories where required.
  • Air/electric workstation or other column-mounted service accessories where compatible.

Workshop fit

BendPak 16AP is rated to 7,257 kg. Key published workshop dimensions in this brief include overall height 4,293 mm, overall width 4,267 mm, inside-column width 3,048 mm and drive-through clearance 2,616 mm. Confirm actual vehicle mass, individual arm loading, centre of gravity/weight distribution, manufacturer lifting points, arm reach, required pads/adapters, vehicle height, bay width, ceiling and overhead services, electrical supply, slab condition/strength/anchoring requirements, unloading access and the exact installation manual before supply. Rated capacity alone does not establish vehicle suitability. AUSTRALIAN AVAILABILITY HOLD: Do not present this model as locally stocked, immediately available or confirmed for Australian supply until Michael/Genesis confirms it. The page may be built in staging so the catalogue is ready.

Frequently asked questions

What is the rated capacity?
7,257 kg, with a published maximum of 1,814 kg per arm.
Its geometry and minimum pad height are aimed more toward larger vehicles. Actual suitability should be checked from lifting points and arm reach rather than capacity alone.
The current manufacturer specification lists approximately 4,267 mm overall width.
A current product page was not found on the supplied Genesis BendPak brand/range pages, so Australian availability must be confirmed before publication.
Yes. Provide vehicle weights, axle loads, lifting points and dimensions so the two-post suitability can be checked.
